24V Telekom Röle HLS-4078-DC24V
24V Telekom Röle HLS-4078-DC24V
24V Telekom Röle HLS-4078-DC24V
24V Telekom Röle HLS-4078-DC24V

24V Telekom Röle HLS-4078-DC24V (İzmo7557)

0,00
Marka : HTV
Fiyat : $0.65  + KDV
KDV Dahil : $0.78
Stok Miktarı : 90

24V Telekom Röle

Ürün Özelliği





Contact Form

2C

Contact Material

Ag+Au

Contact Ratings

1A 120VAC;2A/24VDC

Max Switching Voltage

240VAC/60VDC

Max Switching Current

2A

Max Switching Power

120VA/30W

Initial Contact Resistance

50m Ω Max at 6VDC 1A

Life Expectancy Electrical

100,000 Operations(rated load)

Life Expectancy Mechanical

10,000,000 Operations(no load)







GENERAL DATA :

Insulation Resistance

100M Ω Min at500VDC

Dielectric Strength Between Open Contacts

500VAC 50-60HZ( 1 minute)

Dielectric Strength Between Contacts And Coil

1000VAC 50-60HZ( 1 minute)

Operate Time

6ms max

Release Time

4ms max

Ambient Temperature

-30 ℃ to+70 ℃

Shock Resistance

Malfunction

10G

Destruction

15G

Vibration Resistance

10-55Hz,1.5mm double amplitude

Ambient humidity

40-85% RH

Weight

Approx 5g

Safety Standard

UL CE CQC

COIL DATA: (@20 ℃ )

Rated Voltage (VDC)

Coil Resistance Ω ( ± 10% )

Max Operate Voltage (VDC)

Min Release Voltage (VDC)

Max Applied Voltage (VDC)

0.15W

0.2W

0.36W

0.45W

3

60

45

25

20

2.25

0.15

3.9

5

167

125

70

50

3.75

0.25

6.5

6

240

180

100

80

4.5

0.3

7.8

9

540

405

225

180

6.75

0.45

11.7

12

960

720

400

320

9

0.6

15.6

24

38400

2800

1600

1280

18

1.2

31.2

48

-

11520

6400

5100

36

2.4

62.4

PC Board Layout & Wiring Diagram (Bottom View)
